Double‑chain Stainless Steel Scraper Conveyor B630

Product Overview

The B630 double‑chain stainless steel scraper conveyor is an enclosed bulk material transport machine. It adopts double‑chain traction structure, and material‑contact components are made of stainless steel.

Scrapers pull bulk materials inside the closed housing for horizontal or small‑inclination conveying, preventing material spillage and dust emission. It serves working conditions requiring corrosion resistance and sanitary performance.

In model B630, 630 refers to the effective conveying width of 630 mm. The double‑chain design distributes load to reduce stress on each single chain and improve overall operational stability.

Main Structure & Key Features

• Double‑chain traction system: Two driving chains move scrapers synchronously. Load is shared to handle heavy or abrasive bulk materials and lower chain‑break risk.
• Stainless steel wetted parts: Trough and scrapers in contact with material adopt stainless steel for anti‑corrosion performance, suitable for damp and mildly corrosive materials.
• Fully‑enclosed housing: Closed casing contains material spill‑over and dust to improve site working conditions.
• Multiple inlet & outlet options: Multiple feeding and discharging ports can be arranged for multi‑point feeding or multi‑point discharging.
• Conveying mode: Primarily for horizontal transport; also available for small‑angle upward conveying.

Typical Application

Used for granular and powdery bulk material transfer in grain, chemical, light‑industry and building‑material sectors. Recommended for below conditions:

1. Damp or mildly corrosive materials requiring rust‑proof performance;
2. Sites with strict dust‑control and enclosed‑conveying requirements;
3. Continuous processes demanding multi‑point feeding or multi‑point discharging.

Selection Notes

1. Confirm material characteristics: particle size, moisture content, abrasiveness and corrosiveness to match stainless steel tolerance;
2. Calculate conveying length, capacity and inclination angle;
3. Define quantity and installation position of inlets and outlets;
4. Double‑chain unit needs regular chain tension adjustment to keep synchronous movement of both sides.

Conclusion

Featuring double‑chain load‑bearing and enclosed stainless steel trough, the B630 double‑chain stainless steel scraper conveyor provides a dependable continuous‑transport solution for bulk‑material projects with anti‑corrosion and dust‑control requirements.
